PIPA lite lx Instructions
PIPA lite lx Instructions
EN
EN
Shoulder Belts
1
-
Tighten harness to fit snugly on child’s
shoulders. It is snug if you cannot pinch a fold in
the strap. (28)
2 - Harness straps must be at or just below
shoulders. (29)
3 - To adjust shoulder harness height, remove
child and loosen harness by pressing the
harness adjustment button (30)-1 while pulling
on the harness strap (30)-2 The harness
adjustment button is located inside the slot on
the seat pad.
4 - Open the buckle. Pull loose ends of harness
loop out through slots and place in correct
slot. (31)
DO NOT allow harness to pass over bars.
Repeat process for second shoulder harness
strap.
Product Use
Securing Child in Child Restraint
1
- Place child in Child Restraint in seated position.
(32)
2 - The child should be seated against both the
back and bottom of the seat with no gap
behind the child. DO NOT allow child to slouch.
(33)
Gently guide child’s arms through harness
loops.
3 - Place the child into the infant child restraint
and lock the buckle. (34)(35)(36)(37)
4 - Tighten harness by pulling on the adjuster
strap. Pull any excess harness webbing through
the buckle towards the child’s shoulder and
pull on the adjuster strap. This may need to be
repeated several times for proper fit. (37)
Verify that the harness is snug around the
child’s waist and shoulders.
Harness straps must be at or just below child’s
shoulders to avoid injury. If harness slots need
to be moved, see Shoulder Belts section.
Make sure that nothing interferes with the
harness. Make sure harness is snug around
child and lays flat. Serious injury or death could
occur to a child that is not secured properly.
If child is not secured properly, child could be
ejected in a sudden stop or crash, resulting in
serious injury or death.
Check that Child is Secure
Buckle is fastened.
Harness straps are not twisted.
Harness is snug – A snug harness cannot be
pinched, and should not allow any slack.
