PIPA lite lx Instructions
PIPA lite lx Instructions
EN
EN
Check to make sure the base is securely
installed by pulling on the both ISOFIX
connectors.
5 - After placing the base on the vehicle seat,
extend the load leg to floor. When the load
leg indicator shows green means it is installed
correctly, red means it is installed incorrectly.
(44)
The load leg has 12 positions. When the load
leg indicator shows red this means the load leg
is in the wrong position.
Make sure the load leg is secure by pressing
down on the front of the base.
To shorten the load leg, squeeze the load
leg adjustment button and pull the load leg
upwards. (44)
The completely assembled base is shown as (45)
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (45)-1
The load leg must be installed correctly with
green indicator. (45)-2
Check the installation
Base should not move side to side or
forward more than 1” at belt path.
Installation
WARNING Serious injury or death can
occur. The seat alone cannot be installed in the
vehicle. It must be installed with the base. (38)
Base Installation Using ISOFIX
(Lower Attachments)
1
- Unfold the load leg. (39)
2 - Fit the ISOFIX guides with the ISOFIX anchor
points. (40) The ISOFIX guides can protect the
surface of the vehicle seat from being torn.
They can also guide the ISOFIX connectors.
3 - Rotate the ISOFIX connectors 180 degrees
until they are pointing in the direction of the
ISOFIX guides. (41)
4 - Line up the ISOFIX connectors with the ISOFIX
guides, and then click both ISOFIX connectors
into the ISOFIX anchor points. (42)
Make sure that both ISOFIX connectors are
securely attached to their ISOFIX anchor
points. There should be two audible clicks and
the colors of the indicators on the both ISOFIX
connectors should be completely green. (43)
