PIPA lite lx Instructions
PIPA lite lx Instructions
EN
EN
Attaching Child Restraint to Base
1
- After child is properly secured in infant
carrier, press child restraint on base and listen
for a click. Pull on child restraint to verify
installation. (46)
DO NOT allow child restraint to contact the
vehicle interior (side of car or seat in front)
when installed on base.
2 - To release the child restraint, squeeze the
carrier release button (47)-1 located on the
base and then pull the child restraint up. (47)-2
3 - To remove the base, first push the base toward
the vehicle seat with a light force. (48)
4 - As you push the base toward the vehicle seat,
squeeze the secondary (49)-1 and primary
ISOFIX release buttons (49)-2. For ease of
release, push the secondary button first, then
the primary button.
5 - Press the ISOFIX releasing button to fold the
ISOFIX. (50)
Installation with 3-point-belt
1
- Open the vehicle belt lock-off and route the
vehicle safety belt through the belt path. (51)
2 - Buckle the vehicle belt. Both the shoulder AND
lap belt must be under the blue lock off and
belts must lay flat. (52)
3 - While pressing the base into the vehicle seat
(53)-1, tighten the vehicle belt by pulling
straight along the belt path (53)-2, keeping
both belts laying flat in the lock off.
4 - While the shoulder belt is tight, hook the
bottom of blue lock off and press to close the
lock off on the shoulder and lap belt. (54)
The installed base is shown as (55)
Please ensure that there is no gap between the
vehicle seat and the bottom of the base.
The safety belt must go under the lock off, not
over the lock off. (55)-1
The safety belt must be locked into the buckle.
(55)-2
The load leg must be installed correctly with
green indicator. (55)-3
The child restraint can not be used if the
vehicle safety belt buckle (female buckle
end) is too long to anchor the child restraint
securely. (55)-4
5 - After child is properly secured in infant carrier,
press Child Restraint on base and listen
for a click. Pull on Child Restraint to verify
installation. (56)
DO NOT allow Child Restraint to contact the
vehicle door or seat in front of it.
