1 - For a smaller child, use the top shoulder
harness loops (1) and for a larger child, use the
bottom shoulder harness loops (2).
2 - DO NOT allow harness to pass over base
attachment bars.
3 - Top of child’s head is at least 1” below top of
child restraint.
Handle Adjustment
4 - The infant carrier handle can be adjusted to 3
positions.
5 - To adjust the handle position, squeeze handle
adjustment buttons on both sides (1). Rotate
handle until it clicks into any of the 3 positions.
Handle can be used in vehicle in any locked
position (2).
Be sure handle is locked in the carry position
before lifting child restraint by handle. An
unlocked handle could move unexpectedly,
causing injury to child. Handle MUST NOT
contact the vehicle interior (side of car or seat
in front) when installed.
1 in.
25 mm
1
2
1
2
1
2
3
4
5
25PIPA lite series instructions24 PIPA lite series instructions
