Shoulder Belts
1 - Tighten harness to fit snugly on child’s
shoulders. It is snug if you cannot pinch a fold
in the strap.
2 - Harness straps must be at or just below
shoulders.
3 - To adjust shoulder harness height, remove
child and loosen harness by pressing the
harness adjustment button (1) while pulling on
the harness strap (2). The harness adjustment
button is located inside the slot on the seat
pad.
4 - Turn child restraint over and remove one
harness loop from metal splitter plate.
5 - Pull loose ends of harness loop out through
slots and place in correct slot.
6 - Repeat process for second shoulder harness
strap and then re-attach harness to splitter
plate.
1
2
1
2
3
4
5
6
23PIPA lite series instructions22 PIPA lite series instructions
