1 - Rotate rigid LATCH (lower attachments) down.
2 - Hook rigid LATCH onto vehicle LATCH lower
anchor bars.
3 - Confirm proper installation by pulling on the
base AND also seeing that green is indicated
on the connectors.
The rigid LATCH (lower attachments) must be
attached and locked onto the vehicle anchor
bars.
Additional stability can be achieved with the base
by using the stability leg. For instructions on using
the stability leg see stability leg section.
Check the installation
Base should not move side to side or forward
more than 1” at belt path.
Bubble must be touching line. Use recline
adjustment, if needed, to position bubble.
It is acceptable to install with both LATCH
(lower attachments) and the vehicle belt.
1
2
3
33PIPA lite series instructions32 PIPA lite series instructions
