Attaching Child Restraint to Base
1 - After child is properly secured in child
restraint, press child restraint on base and
listen for a click. Pull on child restraint to verify
installation.
DO NOT allow child restraint or handle to
contact the vehicle interior (side of car door or
seat in front) when installed on base.
2 - To release the child restraint, squeeze the
carrier release button (1) located on the base
and then pull the child restraint up (2).
3 - To remove the base, first push the base toward
the vehicle seat with a light force.
4 - As you push the base toward the vehicle seat,
squeeze the secondary (1) and primary rigid
LATCH release buttons (2). For ease of release,
push the secondary button first, then the
primary button.
5 - Then pull the base off of the bars.
1
2
2
1
1
2
3
4
5
35PIPA lite series instructions34 PIPA lite series instructions
