Nuna Pipa Lite Series User Manual

Installation Using Lap and
Lap/Shoulder Belt
1
- Place vehicle in park and on level ground.
2 - Position base in a forward facing vehicle seat.
Adjust base so bubble touches line.
3 - If necessary, use recline adjustment to position
bubble in level indicator to achieve correct
angle for installation. Recline adjustment locks
into position.
4 - To release recline adjustment, press down on
lock button located under base.
5 - Open the vehicle belt lock off by lifting up.
6 - Route the vehicle belt through the opening
in the base labeled ‘belt here’ and under the
vehicle belt lock off.
1
2
3
4
5
6
37PIPA lite series instructions36 PIPA lite series instructions

Nuna Pipa Lite Series Specifications

General

Usage	4 to 32 lbs, up to 32 inches
Safety Features	Side impact protection
Base	Included
Material	Lightweight aerospace aluminum
Compatibility	Nuna strollers
Harness	5-point harness
Safety Standards	Meets or exceeds FMVSS 213
Weight	5.3 lbs
