Nuna Pipa Lite Series User Manual

2
1
1
2
3
4
40 PIPA lite series instructions 41PIPA lite series instructions
1 - After child is properly secured in child
restraint, press child restraint on base and
listen for a click. Pull on child restraint to verify
installation.
DO NOT allow child restraint or handle to
contact the vehicle interior (side of car door or
seat in front) when installed on base.
2 - To release the child restraint, squeeze the
carrier release button (1) located on the base
and then pull the child restraint up (2).
3 - To remove the base, lift up on the vehicle belt
lock off.
4 - Unbuckle the vehicle belt and un-route the
shoulder and lap belt from the base.
Then remove the base.

Nuna Pipa Lite Series Specifications

General

Usage	4 to 32 lbs, up to 32 inches
Safety Features	Side impact protection
Base	Included
Material	Lightweight aerospace aluminum
Compatibility	Nuna strollers
Harness	5-point harness
Safety Standards	Meets or exceeds FMVSS 213
Weight	5.3 lbs
