Parts List
Make sure all parts are available before assembly. The infant carrier module and
base can be sold separately. If any part is missing, please contact local retailer.
No tools are required for assembly.
1 Head support
2 Seat Pad
3 Shoulder Harness Straps
4 Instruction Manual Storage
Compartment (between seat pad
and plastic)
5 Infant Insert
6 Harness Adjustment Button
7 Adjustment Webbing
8 Safety Buckle
9 Side Guides
10 Stroller Release Button A
11 Canopy Mount
12 Canopy
13 Handle
14 Handle Button
15 Rear Guide
16 Stroller Release Button B
17 ISOFIX Connector
18 ISOFIX Guides
19 Load Leg Adjust Button
20 Side Impact Shield
21 Shield Fold Back Button
22 ISOFIX Adjust Button
23 Infant Carrier Module Release
Button
24 Load Leg Indicator
25 Instruction Manual Storage
Compartment
20
14
16
15
13
11
23
25
24
17
19
18
22
21
8
10
1
2
12
4
3
9
7
6
5
