Nuova Simonelli Appia Compact - 1. DESCRIPTION

Fig. 1
28
EN
COMPACT
KEY
1 Select buttons
2 Delivery buttons
3 Steam knob
4 Steam nozzle
5 Filter holder
6 Single delivery spout
7 Double delivery spout
8 Optical level
9 Pressure gauge
10 Adjustable foot
11 Hot water nozzle
12 Rating plate
13 Main switch
14 Cup warmer (optional)
1. DESCRIPTION
4
3
1
10
13
2
14
7 6
5
8
9
12
11
