Operating Instruction and Documentation
2.30 SPL
- 10 -
3. Technical Information
3.1 Technical ratings
Capacity 3000 kg
Load distribution max. 2:3 or 3:2
in or against the drive on direction
Lifting time approx. 30 sec
Lowering time according to the position of the lever
Hlifting height max.1820 mm
Line voltage 3~/N+PE, 400V, 50 Hz
Vontrol voltage 24 V
Power rating 1,5 kW (Bulgar)
Motor speed 2800 rotation/min
Hydraulik pump (Marzoochi) 5,7 cm³/rotation
Hydraulic pressure approx.230 bar
Pressure control valve approx. 255 bar
Oil tank approx. 10 Liter
Sound level ≤ 75 dB(A)
Connection by customer 3~/N+PE, 400V, 50 Hz
fuse T16A (time-lag fuse)
observe your state regulations
3.2 Safety device
1. Safety device at the carrying arms.
Safety device against unintentional movement.
2. Equalization ropes
Safety device against unequality of the load.
3.
Lockable main switch
Safety device against unauthorised operation
4. Foot-protection at the arms
Safety device to avoid crushing
5. Top limit switch
Safety against collision with the vehicle
6. Optional: additional top limit rope
Safety against collision with the vehicle
7. Press button
If not pressing the button any more, the lift stops the movement.
8. Safety ratchets
Safety device against unintentional lowering
