Operating Instruction and Documentation
2.30 SPL
- 13 -
Electrical Parts List
Q1 Main switch 990129
M1 Motor 991033
F1 Fuse 990299
F2 Fuse 990286
F3 Fuse 990299
S1 Button “lifting! 990334
S5 Button “lowering” 990300
K1 Up contactor 991002
T1 Transformer 991002
S1 Top limit switch 990003
Y1 Magnet coil 980654
Y2 Magnet coil 980654
