Nussbaum ATT HYMAX S 3000 User Manual

OPI_SMART LIFT 2.30 SL-2.35 SL-2.40 SL - HYMAX S 3000-S3500-S4000_V1.2_DE-EN-FR-ES-IT 79
2 System master sheet
2.1 Manufacturer
Otto Nußbaum GmbH & Co.KG
Korker Straße 24
D-77694 Kehl-Bodersweier
2.2 Purpose
The lift is a lifting tool for raising vehicles with a total weight of (* see list) in normal workshop operation at a
maximumloaddistributionof(2:3**)(1:3***)inoragainstthedrive-indirectionAsingleloadfromonlyone
or two lifting arms may not happen.
Setupofthestandardliftinexplosionandreendangeredworkshopsandhumidspaces
(e.g. washing halls) is prohibited.
Lift operation is done directly on the operating column (see Data sheet).
After construction and maintenance changes on load carrying parts the lift must be inspected afterwards
by a specialist who approves the changes. If the set up location is changed, the lift must be checked
again by a specialist and changed approved.
(*)System load of the SL series (SL = SMART LIFT):
• SMART LIFT 2.30 SL / HYMAX S 3000** = 3000 kg
• SMART LIFT 2.35 SL / HYMAX S 3500** = 3500 kg
• SMART LIFT 2.40 SL / HYMAX S 4000*** = 4000 kg
Lifting arm variants
SMART LIFT 2.30 SL
HYMAX S 3000
SMART LIFT 2.35 SL
HYMAX S 3500
SMART LIFT 2.40 SL
HYMAX S 4000
Standard arms 590 – 900 mm
940 – 1495 mm
505 – 823 mm
940 – 1495 mm
570 – 1160 mm
1130 – 1840 mm
MINI-MAX arms (MM) 600 – 980 mm
1000 – 1480 mm
232SL28000TG
– 635 – 1065 mm
1130 – 1840 mm
DT Lifting arm 480 – 870 mm
940 – 1495 mm
570 – 1160 mm
940 – 1495 mm
–
Sport Cars Lifting arm
(SC)
– 590 – 865 mm
840 – 1380 mm
–
