Operating Instruction and Documentation
Sprinter Mobil 3000
- 22 -
5. Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
If the vehicles are very short, the ramps must be taken off to guarantee that all wheels
are free.
If the vehicles are very long, the carrying arms must be pulled out to elongate the rails
with the help of the ramps.
5.1 Lifting the vehicle
• Remove the ramps, if the wheelbase is too short and the wheels are standing on the ramps.
Observe the centre of gravity.
If necessary fold out the extension ramps.
• Block the vehicle against rolling, put into gear.
• Check the dangerous places of the lift and be sure that there are no objects or people in the
immediate area of the lift or on the lift.
• Switch on the control system; main switch on position ”1” (see pic.1)
• Position the polymer supports under the pick-up points which are described by the vehicle
manufacturer. Do not lay them on edge! The vehicle might fall down!
• Raise the lift. Press the button „Lifting“.
• Stop the lifting when the wheels are free to check the safe position of the vehicle on the
polymer pads.
• Lift the vehicle on the working height. Press the button „Lifting“ .
• Observe the complete process.
Pic.1:
operating unit
Button “Lifting”
Button “Lowering”
Main switch
