Assembling Your Veggie Bullet | 2120 | Assembling Your Veggie Bullet
STEP 2:
Place the black BASE PLATE (1B)
inside the SHOOTER attachment
(1A) through the center spindle
and align into place. Make sure
that the BASE PLATE is properly
seated in and aligned with the
spokes on the spindle.
STEP 3:
Using the circular finger grips,
carefully place the SHREDDER /
SLICER BLADE (1C) over the top
of the BASE PLATE (1B) through
the center spindle. Make sure that
the SHREDDER / SLICER BLADE
is properly seated in and aligned
with the spokes on the spindle.
A. For shredding, place
the side labeled “SHRED”
facing upward through the
center spindle.
B. For slicing, place
the side labeled “SLICE”
facing upward through
the center spindle.
BLADE DISCS ARE
SHARP! USE CAUTION
WHEN HANDLING!
S TE P 4:
Fasten SHOOTER LID (1D) to the back of the SHOOTER attachment
(1A) by squeezing the retractable hinge pin on back of the
SHOOTER and holding the SHOOTER LID at 90 degree angle.
Interlock the metal hinge on the LID with the back metal hinge pin, then
release the hinge pin and close the SHOOTER LID flat over SHREDDER /
SLICER BLADE (1C).
SAFETY NOTE: Check to make sure that the lid is securely locked in
place and that the push button on the hinge pin is not pushed in.
BA
1B
90°
