NUVE KN 72 - Control Panel

11
Figure 2 – Communication Unit
Figure 3
5.7. CONTROL PANEL
Figure 4
The functions of F1, F2, F3 and F4 buttons depend on the meaning of the corresponding symbol
appearing on the display. The following table shows the meaning of these symbols.
FUSES
POWER CORD
NC-CONTACT OUTPUT
REMOTE ALARM OUTPUT
USB PORT-1
USB PORT-2
ETHERNET
RS 232
