Nuvo NV-P600 - Product Dimensions and Cable Requirements

4
DIN Rail Player Amplifier and DIN Rail Player Power Supply Dimensions
4.205 in.
(106.8 mm)
2.646 in.
(67.2 mm)
3.543 in.
(90 mm)
2.646 in.
(67.2 mm)
2.102 in.
(53.4 mm)
3.543 in.
(90 mm)
Cable Size Requirements
Wire Wire Size
P600 speaker output wires (L+, L-, R+, R-)
14 AWG-18 AWG
P600 and P601 connection wires (24V +/-) 14 AWG-20 AWG
P601 AC input wires (N, L) Any wire in the 14 AWG-24 AWG range with 600 V insulation
