Features
This unit combines the functions of latch type and WTB-005 (momentary type) foot switches. Both of the unit’s
foot switches may be set to function as either a latch or momentary type(Open,Close) switch.
You can connect to gear equipped with TRS 1/4” (6.35mm) phone jacks using a connection cable with stereo
1/4” (6.35mm) phone plugs at both ends.
The NMP-2 can be used with Loop Core Deluxe for phrase up/down.
It also could be used while close mode even passive status.
Product Description
1 3 4
2
5
7
6
8
1. Foot Switch A
Use this as a switch for the device connected to Jack A or Jack B&A. Refer to “Connections.”
2. Foot Switch B
Use this as a switch for the device connected to Jack B or Jack B&A. Refer to “Connections.”
3. Foot Switch A Indicator
When foot switch A is set to the latch type function, this indicator alternately lights or goes out each time
the
