Specifications
Input Impedance
Magnetic: 1MΩ
Piezo: 4.7MΩ
Send Impedance: 1kΩ
Return Impedance: 1MΩ
Sampling Rate: 44.1kHz
A/D Converter: 32bit
Signal Processing: 32bit
Frequency Response: 20Hz~20kHz - ±1dB
Noise Level: -110dBu (A-Weighting)
Dynamic Range: 120dBu
Current Draw: 180mA
EQ: TREBLE 10dB @ 15kHz ±
MIDDLE 10dB @ 1.8kHz ±
BASS 10dB @ 80Hz ±
Power: 9V DC(Negative tip, Optional ACD-006A adapter)
Dimensions: 105mm(L) x 115mm(W) x 58mm(H)
Weight: 445g
*Specifications and features are subject to change without notice.
Accessories: User manual
Made in China
