26 | MEC 5000, 6500 & 8000/P
www.natvac.com | 800.253.5500
12. Lubricate seal sleeve and
install the endplate on the end
of the rotor and carefully drive
the endplate on the rotor.
13. When the endplate is close
enough to the housing install
the endplate bolts lift the
endplate-rotor assembly to
allow proper alignment of the
bolts and bolt holes and start
the bolts into the housing.
Just prior to making contact with
the housing, lift the endplate -rotor
assembly again to insure proper
clearance between the rotor and
the housing.
Tighten endplate bolts to 35-40 ft lb
of torque.
14. Seat the bearing with a bearing
driver or punch.
