NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 39
OPN
USB
Interface
Type
USB Cable
EECOT
MBF2H516C-
EESOT
MBF2H516A-
EEEOT
MBF2H516A-
EENOT
MBF2M516A-
EECOT
MBF2M516A-
EEEOT
MBF2M516A-
EENOT
Mini USB
Type-B
connector
Use a standard USB Type-B to connect.
BMC Interface
Some DPUs incorporate local NIC BMC (Baseboard Management Controller) hardware on
the board. The BMC SoC (system on a chip) can utilize either shared or dedicated NICs for
remote access. The BMC node enables remote power cycling, board environment
monitoring, BlueField-2 chip temperature monitoring, board power, and consumption
monitoring, and individual interface resets. The BMC also supports the ability to push a
boot stream to BlueField-2.
Warning
Applicable to MBF2H516C-EECOT, MBF2H516C-EESOT, MBF2M516C-
EECOT and MBF2M516C-EESOT.

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
