NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 66
40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2,
10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-KX4, 10GBASE-CR,
10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
InfiniBand: IBTA v1.3
(a)
Auto-Negotiation: HDR100 (2 lane x 50Gb/s per lane), PAM4
256b/257b encoding and RS-FEC, FDR (14.0625Gb/s per lane), QDR
(10Gb/s per lane), DDR (5Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per
lane)
On-board
Memory
Single-channel with 8 DDR4 8 bit + ECC (64bit + 8bit ECC) 16GB @
3200MT/s
128GB eMMC memory (effectively 40GB with high durability)
DPU Power
Supply,Consum
ption and
Airflow
Voltage: 12V
Maximum power available through QSFP56 port: 2.5W (per port)
Power and airflow specifications are provided in NVIDIA BlueField-2
DPUs Power and Airflow Specifications document, which is available at
NVOnline following login.
Environmental
Temperature
Operationa
l
0°C to 55°C
Non-
operational
-40°C to 70°C
(b)
Humidity
Operationa
l
10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Notes:
(a)
The BlueField-2 DPUs supplement the IBTA auto-negotiation specification to get
better bit error rates and longer cable reaches. This supplemental feature only initiates
when connected to another NVIDIA InfiniBand product.
(b)
The non-operational storage temperature specifications apply to the product without
its package.

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
