NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 77
Pin # Signal Name Description Pin # Signal Name Description
A45 GND B45 PETP7
A46 GND B46 PETN7
A47 PERP7 B47 GND
A48 PERN7 B48 RSVD
A49 GND B49 GND
A50 RSVD B50 PETP8
A51 GND B51 PETN8
A52 PERP8 B52 GND
A53 PERN8 B53 GND
A54 GND B54 PETP9
A55 GND B55 PETN9
A56 PERP9 B56 GND
A57 PERN9 B57 GND
A58 GND B58 PETP10
A59 GND B59 PETN10
A60 PERP10 B60 GND
A61 PERN10 B61 GND
A62 GND B62 PETP11
A63 GND B63 PETN11
A64 PERP11 B64 GND
A65 PERN11 B65 GND
A66 GND B66 PETP12
A67 GND B67 PETN12
A68 PERP12 B68 GND
A69 PERN12 B69 GND
A70 GND B70 PETP13
