NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 78
Pin # Signal Name Description Pin # Signal Name Description
A71 GND B71 PETN13
A72 PERP13 B72 GND
A73 PERN13 B73 GND
A74 GND B74 PETP14
A75 GND B75 PETN14
A76 PERP14 B76 GND
A77 PERN14 B77 GND
A78 GND B78 PETP15
A79 GND B79 PETN15
A80 PERP15 B80 GND
A81 PERN15 B81 GND
A82 GND B82 PRSNT2# Mechanical Present
4-pin Vertical USB Connector
The below table provides the 4-pin vertical USB connector on the DPU. For further details,
please refer to USB Interface.
Pin # Signal
1 +5V_USB
2 USB DP
3 USB DN
4 GND
External Power Supply Connector
