Nvidia GeForce GTX 770 User Manual

HARDWARE INSTALLATION

3 Remove any existing graphics card (if there is one). Save hardware
(such as screws and brackets) to use when installing the NVIDIA
graphics card.
!
Attention: If your system has been running for a period of
time prior to opening the panels, it is very important that you
wait until the graphics card in your system has cooled before
taking the card out of the system. Graphics cards get very hot
when they have been operating for any length of time.
4 Remove the slot cover if you do not have a graphics card installed.
Note: The GeForce GTX 770 card is double-wide so it will require
removing two slot covers.

Nvidia GeForce GTX 770 Specifications

General

CUDA Cores	1536
Base Clock	1046 MHz
Boost Clock	1085 MHz
Memory	2 GB or 4 GB GDDR5
Memory Interface Width	256-bit
Memory Bandwidth	224.3 GB/s
TDP	230 W
Recommended System Power	600 W
Architecture	Kepler
GPU	GK104
Memory Clock	7010 MHz
Outputs	Dual-link DVI-I, Dual-link DVI-D, HDMI, DisplayPort
Process	28 nm
OpenGL	4.4
Shader Model	5.0
PCI Express Interface	PCIe 3.0 x16
Maximum Digital Resolution	4096x2160
Maximum Display Outputs	4
SLI Support	Yes
