Nvidia GeForce GTX 770 User Manual


HARDWARE INSTALLATION

5 Plug the GeForce GTX 770 graphics card into the Primary PCI Ex-
press x16 slot on your motherboard. This is often the slot closest to
the CPU but may be the second or third slot. Look for the slot labeled
×16. It will likely be the only PCI Express slot with a retention lever on
the end of the slot or the one closest to the CPU
Note: It is recommended that you install the graphics card
into the primary PCI Express x16 slot. If you install the graphics
card into the secondary slot, your system may not recognize the
graphics card and there will be nothing displayed on the monitor.
Also note that on some motherboard SBIOS, the physical
location of the primary slot can be configured when there are
more than one PCI Express x16 slots.
If you are installing additional GeForce GTX 770 graphics cards for an
SLI configuration, continue with step 6 (2-way SLI) or step 6 and 7 (3-
way SLI). If you are only installing one GeForce card, go on to step 8.
Note: All of the graphics cards in an SLI configuration must be
identical. Therefore, you must have all GeForce GTX 770 graphics
cards.

Nvidia GeForce GTX 770 Specifications

General

CUDA Cores	1536
Base Clock	1046 MHz
Boost Clock	1085 MHz
Memory	2 GB or 4 GB GDDR5
Memory Interface Width	256-bit
Memory Bandwidth	224.3 GB/s
TDP	230 W
Recommended System Power	600 W
Architecture	Kepler
GPU	GK104
Memory Clock	7010 MHz
Outputs	Dual-link DVI-I, Dual-link DVI-D, HDMI, DisplayPort
Process	28 nm
OpenGL	4.4
Shader Model	5.0
PCI Express Interface	PCIe 3.0 x16
Maximum Digital Resolution	4096x2160
Maximum Display Outputs	4
SLI Support	Yes
