HARDWARE INSTALLATION
8 Connect one 6-pin and one 8-pin PCI Express auxiliary power
connector to the top edge of the GeForce GTX 770 graphics card.
Note that the connectors and sockets on the graphics card have a
unique shape and connect one way only.
9 Reinstall the cover on your computer and reconnect any cables that
you removed earlier in the installation.
DisplayPort Connector
Supports single-lane transfer rates
over a single cable. The interface
is primarily used to connect a video
source to a display device such as a
computer monitor.
HDMI (High-Definition Multimedia
Interface) Connector
Supports output of both video and
audio from the PC to a high-definition
television.
DVI Connectors (DVI-I and DVI-D)
Use this to connect a digital display or,
with an adapter, a VGA display.
DVI-to-VGA Adapter
(Optional)
