Nvidia GeForce4 MX Series User Manual

15
4.5 Color Correction Panel
4.5.1. Color Correction Settings
If you are using a GeForceX GPU-based card
, another non-nView nVIDIA
GPU-based card, or have not enabled nView on your system yet,
follow these
steps:
!"Right click from the Windows desktop to display the context menu, click
Propertie
s, the
Settings
tab, and the
Advanced
button.
!"Click the
Color Correction
tab to display the nVIDIA Color Correction panel.
If you are using a nView-based card,
have nView enabled, and want to access
the Color Control Panel from the nView panel,
follow these steps:
!"Open the nView control panel.
!"To access the context menu, right click on a monitor icon that appears on the
nView panel.
!"
Select
Color Correction
from the context menu.
1. Open Color Correction
A.
Active Color Channel:
Allows you
to select the color channel controlled
by the sliders. You can adjust the
red, green or blue channels
individually or all three channels at
once.
B.
Brightness, Contrast, and Gamma
Controls:
The slider controls allow
you to adjust the brightness, contrast,
or gamma values for the selected
color channel.
C.
Diagonal Line/Curve:
A graphical representation of the color curve. This
curve will change in real time as you adjust the contrast, brightness or
gamma.
D.
Selecting
Automatically apply these settings at startup
automatically
restores the color adjustments you have made here when Windows is
restarted.
2.
Note:
If your computer is running on a network, the color will be adjusted
after you have logged on to Windows.

Nvidia GeForce4 MX Series Specifications

General

Memory Clock	166-275 MHz
DirectX	7.0
OpenGL	1.2
Pixel Pipelines	2
TMUs Per Pipeline	2
ROPs	2
AGP	4x
Manufacturing Process	150 nm
Maximum Resolution	2048x1536
RAMDAC	350 MHz
Max Memory	64 MB
Architecture	NV17
Memory Type	SDR, DDR
Memory Bus Width	64/128-bit
