Jetson TX2 Developer Kit DA_09452-003 | 8
Optional Default
Pin
Default Optional
GPIO
35
36
3.3V GPIO UART CTS
GPIO 3.3V 37
38
GPIO
Ground 39
40
GPIO
• [J22] The camera connector supports up to six directly connected cameras via
CSI-2, or up to 12 cameras via the virtual channel feature of CSI-2. The connector
also includes some interface options for audio (I2S & DMIC).
• [J24] The voltage select header enables either 3.3V or 1.8V for these [J21] 40-pin
expansion header pins:
Pins 7, 12, 13, 16, 18, 19, 21, 23, 24, 29, 32, 33, 35, 38, and 40
The 3.3V level is selected when a jumper is on [J24] pins 1-2. The 1.8V level is
selected when a jumper is on [J24] pins 2-3.
• [J25] Use the included developer kit power supply with this DC power jack.
• [J26] 30-pin expansion header includes:
o Power pins.
One 1.8V power pin, one 3.3V power pin, and one 5V power pin. These are
not switchable; power is always available when the developer kit is
connected to power.
o Interface signal pins.
Optional Default
Pin
Default Optional
Not Used 3 4
Ground 11
12
1.8V
GPIO
GPIO 3.3V 13
14
1.8V
GPIO
CAN1 RX
3.3V 15
16
RESET
GPIO
CAN1 TX 3.3V 17
18
1.8V
GPIO 3.3V 19
20
1.8V
To Next Page
