RTX Blade Server DU-09559-001 _v01|7
Chapter3.
BLADE REPLACEMENT
A faulty RTX Blade Server blade can be replaced while power is applied to the system
and the system is running.
3.1.Blade Replacement Overview
This is a high-level overview of the steps needed to replace the blades.
1.
Identify the blade that needs to be replaced in the rack / chassis.
2.
Confirm that the Blade ID LED is lit.
3.
Release the ejector lever locking clip.
4.
Use the lever to eject the blade from the chassis.
5.
Install the new blade in the slot.
6.
Use the lever to fully engage the connectors.
7.
Make sure the clip locks into place.
3.2.Replacing the Faulty Blade
Caution The blade should be replaced within 30 seconds after removal to prevent
overheating of system components.
1.
Identify blade to be replaced.
a) To locate the RTX Blade Server with the faulty blade, look for an illuminated ID
LED.
