RTX Blade Server DU-09559-001 _v01|12
Chapter4.
CHASSIS MONITORING MODULE
REPLACEMENT
The RTX Blade Server blades must be shut down before replacing the chassis monitoring
module.
4.1.Chassis Monitoring Module Replacement
Overview
This is a high-level overview of the steps needed to replace the chassis monitoring
modules (CMM).
1.
Confirm that all the blades in the chassis are powered off.
2.
From the back of the chassis use the ejector lever to pull the Chassis Monitoring
Module out.
3.
Install the new CMM and use the lever to confirm it fully engages with the
connectors.
4.
Confirm the module locks into place.
4.2.Replacing the Chassis Monitoring Module
A faulty chassis monitoring module is indicated by the amber light.
