www.nvidia.com
RTX Blade Server DU-09559-001 _v01|16
Chapter5.
SWITCH MODULE REPLACEMENT
The RTX Blade Server switch module can be replaced while power is applied to the
system, but the blades must not be active.
5.1.Switch Module Replacement Overview
This is a high-level overview of the steps needed to replace the switch modules.
1.
Confirm blades in the chassis are not being used as all network connectivity will be
lost.
2.
Label all cables in case they are not already labeled.
3.
Unplug all cables.
4.
Eject switch module from chassis.
5.
Install replacement switch module.
6.
Plug in all cables following the labels.
5.2.Replacing the Switch Module
1.
Confirm that all blades are powered off by checking that the green LEDs on the front
of the chassis are not lit.
2.
Unplug the Ethernet cables from the switch module and label them if not labeled
already.
3.
Remove the faulty switch module.
a) Release the locking tab and pull on the ejector lever away from the switch module
so the connectors are released from the midplane.
