5.
Rack Rails Fully Inserted and Locked in the Rack Assembly
Pull the rack rails' telescopic extensions all the way to the rack's opposite side, and insert the
latches at the rails' free edges to the rack's slots.A click should be heard as the spring latches
are fully inserted and locking occurs.
Ins
ert
ing
the
Spr
ing
Lat
ch
es
to
the
Ra
ck'
s
Slo
ts
To mount the system into the rack:
While your installation partner is supporting the system’s weight, perform the following
steps:
Two people are required to safely mount the system in the rack.
