Appendixes
The document contains the following appendixes:
Accessory and Replacement Parts
Thermal Threshold Definitions
Interface Specifications
Disassembly and Disposal
Accessory and Replacement Parts
Ordering Part Numbers for Replacement Parts
Part Type Part Number Description Supported
Systems
Rack Installation
Kit
930-9SKIT-00L0
-00A
NVIDIA Tool-Less Rail-Kit for 64x400G and 64x800G Switch SN5400, SN5600
Fan Modules 930-9SFAN-00R
M-00A
NVIDIA FAN Unit, C2P Airflow, for 64x400G and 64x800G
switch
SN5400, SN5600
Power Supplies 930-9SPSU-00R
A-00B
NVIDIA Power-Supply Unit, 3KW AC, C2P Airflow, for
64x800G switch, Power cord included
SN5400, SN5600
Cables and
Harnesses
HAR000631 RS232 Cable - DB9 to RJ45 2M harness 2M for SX67X0 and
SB78X0
SN5400, SN5600
ACC000734 Power Cord Black 250V, 16A 2000MM C19 to C20 SN5400, SN5600
Thermal Threshold Definitions
Three thermal threshold definitions are measured by the Spectrum®-4 ASICs, and impact the overall
switch system operation state as follows:
Warning– 105°C: On managed systems only: When the ASIC device crosses the 100°C
threshold, a Warning Threshold message will be issued by the management software,
indicating to system administration that the ASIC has crossed the Warning threshold. Note
that this temperature threshold does not require nor lead to any action by hardware (such as
switch shutdown).
Critical– 120°C: When the ASIC device crosses this temperature, the switch firmware will
automatically shut down the device.
Emergency– 130°C: In case the firmware fails to shut down the ASIC device upon crossing its
Critical threshold, the device will auto-shutdown upon crossing the Emergency (130°C)
threshold.
This document is preliminary and subject to change.
This document is preliminary and subject to change.
