NZSAT WIND UP - Specifications and Dimensions; Product Specifications; Physical Dimensions

9
Specification & Dimensions
Operation voltage:
9 - 24vdc
Height when raised:
870mm
LNB:
10.75 Ghz
Height when Parked:
180mm
Gain:
60db
Reflector height:
690mm
Frequency range:
11.7 - 12.75 Ghz
Reflector width:
635mm
Colour:
Grey
Operating Radius:
450mm
Weight:
7kg
Operating Diameter:
900mm
Shipping weight:
12kg
Centre of turret to top
of dish when parked:
Length of cable
Coax&elev meter:
750mm
8mtrs
