15CV-R THREE VIEW DRAWING Dimensions(mm)
SPECIFICATIONS
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
39
25
12.8
83.9
71.1
41
70
15
25
27.5
M5x0.8
11
31.4
2.49 cc
(
0.152 cu.in.
)
15.2mm
(0
.598 in.
)
13.7mm
(
0.539 in.
)
4,000〜36,000 r.p.m.
1.2 ps / 31,000 r.p.m.
195g(6.88oz.)
35
15CV-RX THREE VIEW DRAWING Dimensions(mm)
SPECIFICATIONS
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
2.49 cc
(
0.152 cu.in.
)
15.2mm
(0
.598 in.
)
13.7mm
(
0.539 in.
)
4,000〜36,000 r.p.m.
1.2 ps / 31,000 r.p.m.
253g(8.924oz.)
20
91.1
71.1
88.8
M5x0.8
41
33.8
25
11
31.4
40
27.5
