ENGINE PARTS LIST
No. Code No. Description
1 25604100 Cylinder Head
2 25603010 Cylinder Piston Assembly
3 24806301 Piston Pin
4 24817100 Piston Pin Retainer
5 25305002 Connecting Rod
6 25681010 Carburetor (Type 40B)
7 23210007 Propeller Nut
8 24009000 Propeller Washer
9 25608000 Drive Washer
10 46120000 Thrust Washer
11 26731040 Crankshaft Ball Bearing (front)
12 25601200 Crankcase
13 26730040 Crankshaft Ball Bearing (rear)
14 25602021 Crankshaft
15 25614010 Gasket Set
16 25607010 Cover Plate
17 24007120 Needle Stay
18 25681900 Needle Valve Body Assembly
18-1 22681980 Needle Assembly
18-2 24981837 O-ring
18-3 26381501 Set Screw
18-4 26711305 Ratchet Spring
18-5 26582910 Needle Valve Holder
18-6 26582920 Needle Valve Holder Retaining Screw
19 25613000 Screw Set
71605300 A3 Glow Plug
25425000 873 Muffler Assembly
22681957 Pressure Fitting
25425310 Assembly Screw
25425400 Retaining Screw (3x35mm 2 pcs.)
