Installation in the Model
Make sure that the mounting beams are
parallel and that their top surfaces are in the
same plane.
• Before connecting the throttle-
lever/servo linkage, make sure that no
part of the linkage interferes with the
internal structure of the aircraft or
wiring, etc., when the throttle is fully
open or fully closed.
• Set the throttle lever linkage so that the
throttle rotor is (a) fully open when the
transmitter throttle stick is fully
advanced and (b) fully closed when the
THROTTLE LINKAGE
INSTALLATION OF THE ENGINEBASIC ENGINE PARTS
