8
English
7. Installation
– Be sure to read and observe the safety instructions prior to installation!
– Compare the electrical data of the supply grid with that of the type label.
This data must be consistent.
– Install the Bitron at least 6 feet from the edge of the pond!
– Position the Bitron so that it will not be emmersed in water.
– Put the Bitron where it will not be exposed to direct sunlight!
– Lay the hoses and the connecting lead in such a way that they do not
present an obstacle and cannot be damaged!
– You must read and follow the safety instructions before the installation!
– The Bitron devices 18C are suitable for a pump capacity of up to
3960 Gph (15000 l/h). The flow rate on the UVC bulb should not exceed
– 580 Gph (2200 l/h) for Bitron 18C
(see “8.1 Bypass setting”)
– The Bitron devices 36C/55C are suitable for a pump capacity of up to
7920 Gph (30000 l/h). The flow rate on the UVC bulb should not exceed
– 1190 Gph (4500 l/h) for Bitron 36C
– 1720 Gph (6500 l/h) for Bitron 55C
(see “8.1 Bypass setting”)
– Please select the filtration system according to Table 7 (page 47).
Selection criteria: Pond size and with/without fish stock).
A
B
C
D
E
F
G
H
7.1 Device overview
A UVC water discharge
B Rotary handle for water
flow adjustment
C Water discharge bypass
D Water intake
E Foot
F Inspection glass for
inspecting the UVC
bulb and the cleaning
rotor function
G Safety locking lever;
prevents the device
head from being
opened unintentionally.
H Device head, removable
for UVC bulb replacement.
Legend for Table 7 (page 47):
Near natural garden ponds with plants.
Garden and koi ponds with a fish stock up to 2.2 lbs (1000 grams)
per 265 Gal. (1000 litres).
95-08 26866 Bitron_USA.p65 22.01.2008, 15:538
