Connecting the dirt outlet
The soiled water resulting from cleaning can be used for fertilisation. Connect a hose and route it
up to a suitable location (e.g. flower bed).
Use a transparent hose connector with a flow lug. The transparent hose connector will allow you
to assess the degree of soiling of the water when cleaning the foam filters. The flow lug will show
you the water flow.
Push the hose onto the hose connector until only two segments on the hose connector re-
main uncovered.
– This will give you a sufficiently large view into the hose connector.
Always use a hose clip to fasten the hose on a hose connector.
Install the black hose connector with the G2 outer thread on the outlet of the hose. Close the
hose connector with the cover cap and the flat seal.
NOTE
Close the dirt outlet or the outlet of the connected hose with the cover cap and the flat seal.
This prevents unintended emptying of the pond. Only remove the cover cap to drain dirty water.
