Oase FiltoClear 5000 User Manual

54
Technical data
Unit data
FiltoClear 5000 13000 19000 31000
UVC clarifier Connection voltage V AC 220–240 220–240 220–240 220–240
Mains frequency Hz 50/60 50/60 50/60 50/60
Power consumption W 18 24 42 60
UVC power W 18 24 42 60
UVC lamp 18 W
TC-L(UV-C)
24 W
TC-L(UV-C)
36 W/42 W
TC-L(UV-C)
55 W/60 W
TC-L(UV-C)
Protection type IP68 IP68 IP68 IP68
Max. permissible immer-
sion depth in the water
m 0.1 0.1 0.1 0.1
Length of power cable m 5 5 5 5
Min. flow rate l/h 2500 4500 6500 8500
Max. flow rate l/h 5000 9000 13000 17000
Max. permissible pump pressure bar 0.6 0.6 0.6 0.6
Max. permissible operating pressure bar 0.2 0.2 0.2 0.2
Inlet Connection G2 G2 G2 G2
Hose connector mm 38, 50 38, 50 38, 50 38, 50
Outlet Connection G2 G2 G2 G2
Hose connector, transpar-
ent
mm 38, 50 38, 50 38, 50 38, 50
Dirt outlet Connection G2 G2 G2 G2
Hose connector, transpar-
ent
mm 38, 50 38, 50 38, 50 38, 50
Number of red foam filters 1 1 1 2
Number of blue foam filters – 1 2 2
Number of purple foam filters 1 1 1 1
Suitable for max. pond volume l 5000 13000 19000 31000
Suitable for max. pond volume with fish l 2500 7000 10000 15000
Suitable for max. pond volume with koi l – – 5000 7500
Permissible ambient temperature during
operation
°C 0 … +35 0 … +35 0 … +35 0 … +35
Permissible water temperature °C +4 … +35 +4 … +35 +4 … +35 +4 … +35
Dimensions Length mm 391 391 391 391
Width mm 382 382 382 382
Height mm 370 490 611 732
Weight Without water kg 8.0 8.8 9.6 10.3
with water kg 26 36 47 57
