32
1 Water inlet for the pond water being cleaned
Connection G2
2 Opening ring with locking screw for locking the UVC unit head
It is necessary to open the opening ring in order to remove the UVC unit head.
3 Water outlet for the cleaned pond water
Connection G2
4 UVC unit head with temperature monitor
The UVC clarifier shuts down when overheating and automatically turns on again after it has
cooled down
5 Turning valve for switching between water outlet and dirt water outlet
Water filtration and UVC radiation
Cleaning the foam filters
6 Dirt water outlet for the dirt water when cleaning the foam filters
Connection G2
7 Indicator lamp for checking the function of the UVC clarifier
8 Cleaning handle
Pull to compress the foam filters and flush out the dirt particles
9 Filter cover
10 Clamping ring for fastening the filter cover on the container
11 Marking for max. burying depth
12 Container
13 Cleaning rotor, cleans the quartz glass during operation
Only for FiltoClear 19000, 31000
14 Foam filter, blue (10 ppi)
15 Foam filter, red (30 ppi)
16 Foam filter, purple (20 ppi)
17 Closing disc for foam filters, is connected with both cleaning rods
18 Cleaning rod, connecting cleaning handle and closing disc
19 Meshed tube, maintaining the distance between the foam filters and the UVC water housing
20 UVC water housing, conveying water to the UVC lamp
21 Spacers that connect the two spacer discs
The spacers prevent the foam filters from being compressed by the weight of the foam filters
above them
22 Quartz glass with internal UVC lamp
23 Spacer disc, placed between each pair of foam filters
