- EN -
62
7.7 Overview of the "Timer" screen
24 hour scale (0:00 … 24:00)
Time axis for display of the programmed timer.
A time axis is assigned to each socket.
Programmed timers are represented as green bars on the time axis.
The display is adjusted by touch gestures in the area of the time axes:
Swipe to the right or left to show different times.
Make a spreading movement with two fingers to stretch the time axes.
Make a pinching movement with two fingers to compress the time axes.
The green bar shows the time period during which the socket is switched on.
The switch-on time and switch-off time can be read off the 24 hour scale.
For the socket with dimmer, the set percentage value of the dimmer is additionally displayed.
Aids for using small display:
compress time axes.
stretch time axes.
Socket touch symbol
Touch the touch symbol to program a new timer.
