Oasis Modular Series User Manual

16
SECTION10: PARTS BREAKDOWN
ITEM DESC. PART # QTY
1 BUSHING, SNAP 2.5” 027189-012 2
2 GRILLE, DRIPTRAY 042374-001 1
3 SCREW, FLAT HD TAPPING 026675-003 3
4 ASM, VHB ALCOVE 041405-001 1
5 ASM, VHB PCB BRACKET 041405-002 1
6 ASM, VHB IR BRACKET 041405-003 1
7 BUTTON ASSY - EBF 042067-001 1
8 COVER, FRONT 042370-001 1
9 ASSY, LED - EBF 042068-001 1
10 PANEL, EBF UPPER OASIS 041374-101 1
11 PANEL, MWSBF LOWER LOUVER 027697-005 1
12 LOCK ASSY 031657-006 2
13 POWER SUPPLY, 12VDC 038036-003 1
14 PCB, IR SENSOR 042065-001 1
15 LENS, PWEBF LCD 042575-001 1
16 SPOUT 042369-001 1
17 LEAD WIRE ASSY 10FR (BLACK) 017340-512 1
18 LEAD WIRE ASSY 10FR (RED) 021929-129 1
19 SOLENOID VALVE 12VDC 038030-002 1
20 FTG, PP REDUCING UNION 028668-101 1
21 ADAPTER, FLOW NOZZLE 038029-001 1
22 FLOW NOZZLE ASSY 038032-001 1
23 LENS, IR BOTTLE FILLER 038027-001 1
24 LEAD WIRE ASSY 16GG (GREEN) 021339-177 1
25 LEAD WIRE ASSY 24GG (GREEN) 021339-149 1
26 DRIPTRAY, SURFM 042372-001 1
27 ANGLE, CRADLE MTG 026210 2
