Hardware Features
Flame LEDs
The Flame features two indicator lights that operate as shown:
Cables and Connectors
Cables are available to connect your Flame Spectrometer to accessories:
• Accessory cable for light sources and other accessories (DB15 Connector Cable)
• Accessory cable for HR-type connector (PAK50 Connector Cable)
• Breakout board (DD4 -BREAKOUT-BOARD ) This breaks out the 40 pin DD4 connector to a set of header pins that can be used
to wire each pin, as required.
DB15 Connector Cable (FLAME-CBL-DD4P-DB15P)
This cable connects the Flame to existing Ocean Insight accessories that use a DB-15HD connector. These include the PX-2, LLS and
HL-2000-FHSA light sources.
