Ocean Insight FLAME - Electrical

MNL-1012 Rev A
12
Specification
FLAME-S
FLAME-T
Corrected linearity
>99.8%
Filters (optional)
2
nd
and 3
rd
order rejection, long pass
Electrical
Power requirement (spectrometer
functions)
250 mA at +5 VDC
Supply voltage
4.75 – 5.25 V
Power-up time
~2s
Connectors
Micro-USB and JAE DD4 (DD4RA40JA1) 40-pin connector
Micro-USB Absolute Maximum
Ratings:
V
CC
+ 5.5 VDC
DD4 Absolute Maximum Ratings:
V
CC
(Pin 40)
Voltage on any pin (other than input
power)
+ 5.5 VDC
+4VDC
Interface:
USB
RS-232
USB 2.0, 480 Mbps
2-wire RS-232
Mechanical
Spectrometer Design
Asymmetric crossed Czerny-Turner
Input Fiber Connector
SMA 905 or FC
Gratings
15 different gratings.
Entrance Slit
5, 10, 25, 50, 100, or 200 μm slits. (Slits are optional. In the absence of a slit, the fiber acts as
the entrance slit.)
