40 www.ochsner.com | PIA-982027-AIR 85-td-EN
Data table
SPECIFICATION
13. Data table
APPLIANCE DATA AIR 85 C14A
Order no. 288800V
Suitable building heat load kW 50 - 78
Max. flow temperature °C 65
Indoor unit
AIR 85 C14A
Dimensions (HxWxD) mm 1889x680x698
Hydraulic assembly connection (dimension) inch 2
Hydraulic assembly connection (connection type) Male thread
Liquid line connection (external diameter) mm 22
Suction gas line connection (external diameter) mm 42
Weight (excl. packaging) kg 295
Standard colour White/anthracite
Sound power level (EN12102) dB(A) 63
Sound pressure level (at 1 m) dB(A) 55,2
Outdoor unit
AIR 85 C14A
Dimensions (HxWxD) mm 1340x2224x1940
Weight (excl. packaging) kg 360
Standard colour Grey (RAL 7016)
Casing type Stainless steel, coated
Number of fans pce 4
Sound power level (EN12102) / Sound pressure level
(at 3 m)
dB(A) 67 / 49.6 Nominal
Sound power level (EN12102) / Sound pressure level
(at 3 m)
dB(A) 64 / 46.6 Silent mode
Evaporator type Finned tube
Evaporator material (WQA) Copper/aluminium
REFRIGERANT CIRCUIT AIR 85 C14A
Refrigerant R410A
Refrigerant charge kg 32
Max. refrigerant operating pressure bar 45
Compressor type Scroll
Defrost technology Hot gas/reversal system
ELECTRICAL DATA AIR 85 C14A
Frequency Hz 50
Power factor 0,85
Voltage fluctuations/flicker >16 A: EN 61000-3-11
Harmonics >16 A: EN 61000-3-12
Max. network impedance (Zmax) ohm 0,472
Main power circuit
AIR 85 C14A
Rated voltage range V ~380-400 3/N/PE
Rated current A 63
Max. starting current A 95,6
Fuse protection 1x C63A 3p
