What to Do if Water is in the Air
Filter Housing
Inspect the drain reservoirs in the
back of the front left wheel inner
fender to validate if water is present.
TYPIAL
1.Clean air filter housing drain reservoir
2. Dirty air filter housing drain reservoir
If water is present, press clamps and
remove reservoirs to drain water
from air filter housing.
If one of the following conditions is
met, bring the vehicle to your nearest
authorized ATV dealer to have the
vehicle serviced:
-If more than 50 ml of water is
found in the clean chamber drain
hose.
- If any deposits are present in the
clean chamber drain reservoir.
- If either hose is obstructed.
In such a case, the vehicle must be
serviced for:
-Air filter housing cleaning.
-Vents (radiator cooling fan, water
pump, coolant reservoir, fuel tank,
gearbox, front differential and rear
final drive)
- CVT air filter cleaning
-CVT cleaning
-Lubricant inspection and
replacement as required (engine,
gearbox, front differential and rear
final drive).
NOTE:
Failure to have vehicle serviced
may lead to permanent damage to
the following components but not
limited to:
-Engine and gearbox
-Fuel pump
-CVT
-Cooling fan
-Front differential
-Rear final drive
What to Do if Vehicle is
Turned Over
When vehicle is turned over or stays
tilted on the side, put the vehicle back
on its wheels. Inspect vehicle for
damages.
If vehicle has no damage, refer to
MANTENANCE section and inspect
the following.
- Inspect air filter housing for oil
accumulation, if any oil is found,
clean air filter and air filter housing.
-Check engine oil level and refill in
necessary.
- Check engine coolant level and
refill if necessary.
-Check gearbox oil level and refill if
necessary
-Check rear final drive oil level and
refill if necessary.
