ODU AMC
®
HIGH-DENSITY
BREAK-AWAY PLUG
ASSEMBLY INSTRUCTION
4 Assembly crimp sleeve
4.1 Crimp tool ODU
Hand-crimptong
Size Part number
all 080.000.026.000.000
Crimp dies
Size Part number
00 (C)
080.000.026.713.001
0 080.000.026.701.000
1 080.000.026.715.000
1.5 (A) 080.000.026.702.000
4.2 Band-It Bands
To connect the shielding with the crimp adapter,
using a Tie-Dex Micro Band.
Hand-crimptong
Size Part number
all
080.000.058.000.000
Tie-Dex Micro Band
Size Part number
all
921.000.004.000.248
